Hearthstone Wood Stoves: Castleton (2020 CERTIFIED)
CLASSIC STYLE WITH THE ESSENTIALS
The Castleton gives you the heating qualities of soapstone and the detailing of fine cast iron. Designed to maintain a warm, consistent heat, the Castleton is simple, reliable, affordable, and beautiful.
2020 CERTIFIED
Cast iron interior impact plates:
protect the soapstone when loading the stove
Top or rear flue exit:
flexible installation
Single lever stove control:
easy operation, consistent performance
Non-catalytic combustion system:
clean burning, efficient, reduces creosote build-up
Ember Protection Only Hearth Requirement
Specifications
| Heats up to | 1,500 |
|---|---|
| Burn Time | up to 8hr |
| Heat Life | up to 10 hr |
| Size | 45,000 BTUs |
| EPA Rating | 2.7 grams/hr |
| Efficiency | 78% |
| Width | 25.5" |
| Height | 26" |
| Depth | 24" |
| Maximum Log Length | 18" |
| Firebox Capacity | 1.9 cu. ft. |
| Flue Exit & Diameter | Top or Rear-6" |
| Optional Blower Kit | Yes |
| Actual Weight (lbs.) 105 LBS. | 464lbs |
| Alcove Certified | Yes |
| Mobile Home Certified | Yes |
Clearances (With single wall pipe & no rear heat shield)
| Side | 20" |
|---|---|
| Rear | 18" |
| Corner | 10" |
Clearances (With double-wall pipe & rear heat shield)
| Side | 15" |
|---|---|
| Rear | 6" |
| Corner | 10" |
Hearth Pad
| Minimum R-value | Ember Protection only |
|---|
